Optical Multimeter

with laser source and optical power meter

AOMM-FHM2

Type	Measuring devices

Order number	00212203
EAN-Code	4026187210397

Product Details

Triple wavelength optical multimeter with laser source and optical power meter
detect wavelength: 850/1300/1310/1490/1550/1625 nm; launch wavelength: 1310/1490/1550 nm; measure range: -50 to +26 dBm
create a simple loop measurement for detection of insertion loss for splitters / wdm filters etc. with one device
Optical power meter: 850/1300/1310/1490/1550/1625 nm / 50 dBm to +26 dBm
Laser source: three output wavelength at one output interface
Both continuous wave and modulated wave are available; the frequency of modulated signal is 270 Hz, 1 kHz, 2 kHz
Back light display
Integrated with charging circuit
Data storage up to 999 test results
USB interface for connecting PC with assorted sofware
Automatic shutdown in low power status
